Description
Operating Data
Temperature (min)
-269 °C
Temperature (max)
250 °C
Pressure (max)
80 bar
Gasket characteristics EN 13555
Gasket characteristics DIN 2505 V
K0×Kd [N/mm2]
24 × bd
k1 [mm]
1,2 × bd
Gasket characteristics DIN 28090
6vo [N/mm2]
160
6vu 0,1 [N/mm2]
24
m (DIN 28090)
1.2
6BO 150 °C [N/mm2]
110
6BO 200 °C [N/mm2]
90
Gasket characteristics ASME
m (ASME)
1.5
Y [PSI]
3700
Approvals & Test Reports
TA Luft 2002 (VDI 24A0/2200)
DIN EN13555 (TA Luft 2021)
Blow-out resistance
FDA (Food)
EG 1935/2004
Flange Shapes
Self-centering, Raised Face (form IBC)
Male-Female (form SR)
Glass-lined, Enamelled flange
Apparatus, customized
