Description
Operating Data
Temperature (max)
200 °C
Pressure (max)
40 bar
Gasket characteristics EN 13555
Gasket characteristics DIN 2505 V
K0×Kd [N/mm2]
13 × bd
k1 [mm]
1,1 × bd
Gasket characteristics DIN 28090
6vo [N/mm2]
50
6vu 0,1 [N/mm2]
13
m (DIN 28090)
1.1
6BO 150 °C [N/mm2]
30
6BO 300 °C [N/mm2]
120
Gasket characteristics ASME
m (ASME)
1.5
Y [PSI]
2000
Approvals & Test Reports
DIN EN13555 (TA Luft 2021)
BAM oxygen
FDA (Food)
Flange Shapes
Self-centering, Raised Face (form IBC)
