Description
Operating Data
Temperature (min)
-269 °C
Temperature (max)
260 °C
Pressure (max)
40 bar
Gasket characteristics EN 13555
Approvals & Test Reports
TA Luft 2002 (VDI 24A0/2200)
DIN EN13555 (TA Luft 2021)
Gas (DIN 30653 (ehemals VP401; HTB))
WRAS
FDA (Food)
EG 1935/2004
Flange Shapes
Self-centering, Raised Face (form IBC)
Male-Female (form SR)
Glass-lined, Enamelled flange
GRP flange
Plastic flange
Apparatus, customized
Forms of delivery
Spool length: 5, 10, 25, 50 m
3 x 1,5 mm
5 x 2 mm
7 x 2,5 mm
10 x 3 mm
12 x 4 mm
14 x 5 mm
17 x 6 mm
20 x 7 mm
25 x 5 mm
28 x 5 mm
40 x 5 mm
