Description
Operating Data
Temperature (min)
-269 °C
Temperature (max)
250 °C
Pressure (max)
80 bar
Gasket characteristics EN 13555
Gasket characteristics DIN 28090
6vo [N/mm2]
210
6vu 0,1 [N/mm2]
20
m (DIN 28090)
1.2
6BO 150 °C [N/mm2]
110
6BO 200 °C [N/mm2]
90
Approvals & Test Reports
TA Luft 2002 (VDI 24A0/2200)
DIN EN13555 (TA Luft 2021)
Blow-out resistance
BAM oxygen
FDA (Food)
Flange Shapes
Self-centering, Raised Face (form IBC)
Male-Female (form SR)
Glass-lined, Enamelled flange
Apparatus, customized
