Description
Operating Data
Temperature (min)
-50 °C
Temperature (max)
250 °C
Pressure (max)
125 bar
Gasket characteristics DIN 2505 V
K0×Kd [N/mm2]
42 × bd
k1 [mm]
2 × bd
Gasket characteristics DIN 28090
6vo [N/mm2]
230
6vu 0,1 [N/mm2]
42
m (DIN 28090)
2
6BO 200 °C [N/mm2]
100
Gasket characteristics ASME
m (ASME)
3
Y [PSI]
6000
Approvals & Test Reports
Fire Safe Test
Gas (DIN 3535-6)
Gas (DIN 30653 (ehemals VP401; HTB))
WRAS
FDA (Food)
EG 1935/2004
Flange Shapes
Self-centering, Raised Face (form IBC)
Tongue and Groove (form TG)
Male-Female (form SR)
Apparatus, customized
With partition bars
