Description
Operating Data
Temperature
450 °C
Temperature (min)
-269 °C
Temperature (max)
550 °C
Pressure (max)
40 bar
Gasket characteristics DIN 2505 V
K0×Kd [N/mm2]
30 × bd
k1 [mm]
1,3 × bd
Gasket characteristics DIN 28090
6vo [N/mm2]
120
6vu 0,1 [N/mm2]
30
m (DIN 28090)
1.3
6BO 300 °C [N/mm2]
100
Gasket characteristics ASME
m (ASME)
2
Y [PSI]
1500
Approvals & Test Reports
BAM oxygen
Flange Shapes
Self-centering, Raised Face (form IBC)
Glass-lined, Enamelled flange
