Description
Operating Data
Temperature
450 °C
Temperature (min)
-269 °C
Temperature (max)
550 °C
Pressure (max)
100 bar
Gasket characteristics DIN 2505 V
K0×Kd [N/mm2]
35 × bd
k1 [mm]
1,3 × bd
Gasket characteristics DIN 28090
6vo [N/mm2]
140
6vu 0,1 [N/mm2]
35
m (DIN 28090)
1.3
6BO 300 °C [N/mm2]
100
Gasket characteristics ASME
m (ASME)
2
Y [PSI]
1500
Approvals & Test Reports
Gas (DIN 3535-6)
Flange Shapes
Self-centering, Raised Face (form IBC)
Apparatus, customized
With partition bars
